Our 20- horsepower steam engine is:

This two-cylinder, 20-horsepower, 3 x 4-inch, double-acting, 90° "V" engine is designed in the simplest possible form for steady-state power production.

It will produce 20 hp with a maximum of 200 psig @ 700 rpm. It will drive a 15,000 kw generator. It is well balanced for those parameters and is designed for self-starting. Its low-speed torque is in the order of 200 ft-lb and should be handled carefully.


It has very large balanced piston valves that will greatly increase its efficiency and can stand a considerable amount of superheat. Its nominal cutoffs are 55% admission and 65% exhaust. Cylinder clearance volume is in the order of 12–13% and will allow for moderate compression, which helps in starting the engine from cold. Admission starts at 1% before dead centers to aid in high-speed running with the standard 55° eccentrics.


 $5,850.⁰⁰
Plus shipping and handling

Note: $2,000.00 deposit due with order by certified check or money order. Allow approximately three-months for delivery.

For more information call
1-866-965-3007
